RAV-MS-4x2DLHU-Tx/Rx

Limited Quantity.
Call Us to discuss.

Unlock your meeting room’s potential  with the RAV-MS-4x2DLHU-TxRx.

This presentation auto-switcher extender and first launch of a product that supports HDBaseT video 3.0 and USB 3.2 Gen 1 over Cat6, features four inputs on the transmitter and three inputs on the receiver.

Output is to two independent HDMI displays at a distance of 100 metres. USB-C inputs are fully featured, supporting DP-Alt mode for extended screen, charging at up to 100w, and 1G Ethernet. In addition with the device’s auto-switching and USB hub host/device access, the RAV-MS-4x2DLHU-TxRx will meet the demands of professional installations.

HDMI USB-C 100W HDBT 100m
£ 0.00 £ 0.00
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

RAV-MS-4x2DLHU-Tx/Rx
4×2 USB-C & HDMI Matrix Switcher with HDBT 3.0 & USB 3.2

The RAV-MS-4x2DLHU-TxRx is a dual HDBaseT presentation auto-switcher extender and first launch of a product that supports HDBaseT video 3.0 and USB 3.2 Gen 1 over Cat6.
Featuring four inputs on the transmitter and three inputs on the receiver it can then output to two independent HDMI displays.
USB-C input is fully featured, supporting DP-Alt mode for extended screen at a distance of 100m, charging at up to 100w, and 1G Ethernet.
Designed for high-demanding environments, with analogue audio embedding & de-embedding, RS-232 & IP control, GPI/O, IR Learning, EDID management, dual 1Gb LAN with 802.1x, VLAN and Power-over-Cabe means the RAV-MS-4x2DLHU-TxRx meets today’s video & audio extension challenges.
