RAV-SW-2x1HU is is our smallest professional auto switcher. USB-C and HDMI+USB inputs accommodate sharing of three USB devices between two switchable hosts.
Designed to be cost effective, RAV-SW-2x1HU allows choice of inputs ideal for huddle spaces and small meeting rooms.
RAV-SW-2x1HU is a professional USB-C and HDMI+USB Auto Switcher enabling seamless switching between two laptop hosts; one on USB-C and the other on HDMI & USB.
Effortlessly switch three USB peripherals and one display between the two hosts.
Compatible switching uses include a room PC with laptop, a wireless solution with laptop or simply 2x BYOM devices.
Switching operation can be accomplished automatically upon connection of a laptop, TCP/IP, RS-232 and front panel push button.
It can be widely used for sharing USB devices facilitating video conferencing, keyboard & mouse devices, touch panel displays and other USB devices.
Advanced features such as Dual Ethernet ports, USB-C charging, CEC and EDID management are included.
| Inputs: | 1x USB-C Host, 1x HDMI, 2x USB-B, 1x USB-C (Data), 2x 1Gb Ethernet, 1x RS-232 3pin-3.5mm phoenix, 4x USB-A 3.0, 1x DC port. |
|---|---|
| Outputs: | 1x HDMI, 1x 3.5mm (line level), 1x 3.5mm IR extension. |
| Features: | • HDMI™ input up to 4K60Hz 4:4:4, as specified in HDMI™ 2.0b. • Fast switching including auto and manual switching. • Auto switching supports signal detection and 5V detection. • USB 3.2 Gen 1 (5Gbps) host and local hub. • USB 3.2 Gen 1 (5Gbps) device with 5V/1.5A power output. • Support balanced/un-balanced analogue audio embedding to USB or HDMI audio. • Support balanced/un-balanced analogue audio de-embedding from USB or HDMI™ audio. • Advanced EDID management. • User defined welcome screen and no signal display image. • Dual 1G Ethernet ports with 802.1x and VLAN. • IR eye for IR learning and control. • Auto display on/off control. • External device control via CEC/IR/RS-232/LAN/GPIO. • Control via front panel buttons, RS-232, TCP/IP and Web GUI control. • USB-C with 100W power delivery. • Ethernet over USB-C. |
| Country of Origin: | Taiwan (TAA) or China. |
